Bright, Compact, Durable

The LSD400W incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods of use.

3rd-gen Laser Phosphor Technology

Clear Visuals for Business and Education Environments

Thanks to the latest laser technology, the LSD400W achieves high brightness of 4,000 ANSI Lumens. With WXGA resolution​, the projector ensures bright and detailed images in dim or lit environments.

4,000 ANSI Lumens, WXGA

Unmatched Contrasts, Enhanced Visibility

Experience enhanced visuals with the LSD400W, boasting high contrast thanks to DLP technology and an advanced 0.65" DMD chip from Texas Instruments. This provides deeper blacks and richer depth, ensuring an exceptional viewing experience.

0.65” DMD Chip, High Native Contrast Ratio

Ultra-Large Screen with Lower Cost-per-Inch

This easy-to-install projector allows for an image size of up to 300”, offering a lower cost-per-inch compared to other types of commercial displays.​

Up to 300”

Save on Costs and Energy

With its advanced lamp-free light source, the LSD400W offers a highly energy-efficient and cost-saving display solution by consuming up to 49% less power than competing projectors.

Less Power Consumption

Reliable Long-Term Performance with DLP Projection Technology​

With DLP technology, the LSD400W maintains consistent color performance over time, free from any yellowing issues. Featuring a sealed engine design (IP6X), it is filter-free, preventing dust from affecting internal components and ensuring minimal maintenance. Moreover, it offers crisp and seamless image quality, displaying remarkable contrast and eliminating the noticeable screen-door effect.

Filter-free, Sealed Engine (IP6X)

Get ​​Perfectly-Shaped Images Effortlessly

Horizontal and vertical keystone correction, along with 4-corner adjustment features, eliminate crooked or distorted images for a perfectly proportioned picture every time.

H/V Keystone Correction, 4-corner Adjustment

Versatile Creative Application​s

The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.

360° Projection, 90° Portrait Mode

Brilliant Colors for an Authentic Golf Experience

Powered by ViewSonic’s advanced color-tuning technology, the projector features a dedicated Golf Mode that enhances colors, especially greens and blues, more vivid and brings fairways and putting surfaces to life with striking realism, creating a golf experience that feels as close to reality as possible.

Golf Color Mode

Upgrade Your Projector with Wireless Content Casting

Enhance your projector with the ViewShare Wireless Screen Casting Kit for seamless wireless content sharing. The projector‘s built-in 5V/1.5A USB-A output powers the dongle, enabling simultaneous multimedia streaming and power charging without adapters. *ViewShare sold separately

ViewShare​, USB-A Power Supply

A Simpler Way to Update Projector Software

Skip trips to the service center by keeping software up to date easily via USB cable connection with your laptop. This efficient solution, developed exclusively by ViewSonic, ensures optimal performance without the hassle.Learn more: https://youtu.be/irlhJLpDHas*The latest projector software update can be found in the download section at the bottom of the page when available.

Projector Software Update

Dimension & I/O Ports

• 1. Front IR
• 2. Lens
• 3. Focus Ring

• 4. HDMI x2
• 5. RS232
• 6. USB-A (5V/1.5A, Service)

• 7. Audio Out
• 8. DC in
• 9. Zoom Ring

• 10. Power Button
• 11. Keypad
• 12. Top IR

Projection System

0.65" WXGA

Native Resolution

1280x800

Brightness

4000 (ANSI Lumens)

Brightness (Center Lumens)

4800

Contrast Ratio

3000000:1

Display Color

1.07 Billion Colors

Light Source Type

Laser Phosphor

Light Source Life (hours) with Normal Mode

20000

Light Source Life (hours) with SuperEco Mode

30000 (Eco)

Lens

F=2.4-2.53, f=21.85-24mm

Throw Ratio

1.544-1.72

Optical Zoom

1.1X

Digital Zoom

0.8x-2.0x

Image Size

30"-300"

Throw Distance

1-11.11m (100"@3.33m)

Keystone

H:+/-30° , V:+/-30°

Audible Noise (Normal)

30dB

Audible Noise (Eco)

25dB

Input Lag

25ms

Resolution Support

VGA(640 x 480) to WUXGA RB(1920 x 1200) *RB-Reduced Blanking

HDTV Compatibility

480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Horizontal Frequency

15K-102KHz

Vertical Scan Rate

24-120Hz

HDMI

2 (HDMI 1.4, HDCP 1.4)

Audio-out (3.5mm)

1

Speaker

3W

USB Type A (Power)

1 (5V/1.5A)

RS232 (DB 9-pin male)

1

USB Type A (Services)

1 (share with USB A Output)

Power Supply Voltage

Power adaptor: Input: 100~240V Output: 19.5VDC / 9.23A

Power Consumption

Normal: 114W Standby: <0.5W

Operating Temperature

0~40℃

Operating Temperature

Carton: Brown

Net Weight

3.10kg

Gross WEight

4.60kg

Dimensions (WxDxH) with Adjustment Foot

286x216x129mm

Packing Dimensions

400x280x155mm

OSD Language

English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese,Japanese, Turkish, Portuguese, Finnish, Indonesian, Arabic, Vietnamese, Hungarian, Norsk, total 23 languages

User Guide Language

English, S-Chinese, T-Chinese, Indonesian, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Arabic, Czech, Thai, Vietnamese, total 20 languages

Power Cord

1

Wall/Ceiling Mount

PJ-WMK-007

Carry Bag

PJ-CASE-008
